Custom Aramid Felt Conveyor Belt for Aluminum Handling
Seamless aramid felt conveyor belt manufactured by IKSONIC. Custom endless length 1.85–10 m and width 0.35–1.2 m; confirm thickness and temperature exposure for the application.
- Description
- Contact Us
Description
Custom Aramid Felt Conveyor Belt for Aluminum Handling
IKSONIC manufactures custom aramid felt conveyor belts in China for aluminum-industry handling and conveying equipment. Confirm the material specification and supporting documentation for your application.
We offer a yellow, seamless felt belt for aluminum-industry production and conveying equipment. Its soft surface is intended to support contact with the conveyed material. Confirm the finished belt specification, contact conditions and equipment requirements before ordering.
Specifications and Custom Size Range
| Item | Specification |
|---|---|
| Product | Heat-resistant aramid felt conveyor belt |
| Material identification | Aramid; confirm the required material documentation |
| Color | Yellow |
| Belt construction / joint | Seamless endless belt |
| Custom endless-belt length | Minimum 1.85 m; maximum 10 m |
| Custom belt width | Minimum 0.35 m; maximum 1.2 m |
| Thickness | Confirm for the requested belt |
| Maximum temperature reference | 600°C; exposure duration and test method are to be confirmed |
| Application | Aluminum-industry production machinery and conveyor equipment |
| General material features | Soft surface, heat resistance and wear resistance; confirm application requirements |
Temperature selection: Treat 600°C as a maximum reference, not a continuous operating rating. Confirm the temperature at the belt contact surface, exposure duration, load and supporting technical documentation for the actual application.
The dimensions above define the custom size range, not a fixed model schedule. Specify the required endless length and width separately. Specify the required thickness and tolerances in your inquiry.
Information Needed for Selection
- Provide the conveyor layout and the required endless-belt length, width and thickness.
- Describe the aluminum product or other conveyed material, contact surface and load.
- State the belt-contact temperature and exposure duration, including starts, stops and intermittent contact.
- Provide the equipment speed, roller arrangement and any existing belt reference.
- Specify quantity and the material-identification or inspection documents you require.
Please specify the required belt configuration for manufacture. The soft contact surface is intended to reduce marking, but surface protection depends on actual cleanliness, loading and operating conditions; confirm it for your process rather than assuming damage-free handling.
Frequently Asked Questions
Is 600°C a continuous operating temperature?
Confirm the continuous operating rating for your application. The stated maximum needs application-specific confirmation, including exposure duration and contact conditions.
Is this an IKSONIC-manufactured belt?
Yes. This conveyor belt is manufactured by IKSONIC. Confirm the dimensions and application-specific requirements for your order.
Can I order a particular endless-belt size?
We offer custom lengths from 1.85 to 10 m and widths from 0.35 to 1.2 m. Please provide the exact dimensions and thickness for your required configuration.
Does this product establish food-contact approval?
No food-contact approval is claimed for this aluminum-handling belt. Tell us if your application requires specific compliance documentation.
Request a Belt Quotation
For wholesale custom aramid felt conveyor belt inquiries, contact IKSONIC with the belt dimensions, equipment details, temperature conditions and quantity.
Worldwide Delivery
Manufactured in China and shipped worldwide. For orders suitable for international express, delivery typically takes 3–7 days after dispatch, excluding production and order preparation. Transit times vary by destination and customs clearance. Confirm the shipping method and estimated transit time for your order.
