IKSONIC PTFE Nonstick Conveyor Belt for High-Temperature Drying
IKSONIC manufactures endless PTFE nonstick conveyor belts for screen-printing, microwave-processing and tunnel-drying equipment. Eight thicknesses span 0.25–1.0 mm, with maximum widths of 2400 or 2600 mm depending on thickness. Confirm finished dimensions and construction.
- Description
- Contact Us
Description
PTFE Nonstick Conveyor Belt for High-Temperature Processing
This PTFE nonstick conveyor belt is an endless belt for screen-printing, microwave-processing and tunnel-drying equipment. The range includes eight thicknesses from 0.25 to 1.0 mm, with maximum widths of 2400 or 2600 mm depending on thickness. White, brown and black are available for every thickness.
IKSONIC manufactures PTFE conveyor belts in China for wholesale orders. Use the specification table to identify the material thickness and width range you need, then confirm the finished belt dimensions and equipment requirements before ordering.
Product Overview
- Product type: PTFE nonstick conveyor belt.
- Configuration: Endless belt.
- Applications: Screen-printing, microwave-processing and tunnel-drying equipment.
- Thickness options: 0.25, 0.30, 0.35, 0.50, 0.65, 0.75, 0.90 and 1.0 mm.
- Maximum width: 2400 mm for the 0.25 mm thickness; 2600 mm for the other seven thicknesses.
- Colors: White, brown and black.
- Surface characteristic: Nonstick surface for applications requiring release from the belt.
PTFE Conveyor Belt Specifications
The following table shows all eight thickness options. Maximum width is a material-width limit, not a fixed finished belt width. The tensile-strength values use the notation shown, including N±50N/5CM, without conversion or reinterpretation.
| Thickness (mm) | Maximum width (mm) | Tensile strength (notation retained) | Colors |
|---|---|---|---|
| 0.25 | 2400 | 1422N±50N/5CM | White, brown, black |
| 0.30 | 2600 | 1642N±50N/5CM | White, brown, black |
| 0.35 | 2600 | 1722N±50N/5CM | White, brown, black |
| 0.50 | 2600 | 1822N±50N/5CM | White, brown, black |
| 0.65 | 2600 | 2252N±50N/5CM | White, brown, black |
| 0.75 | 2600 | 2642N±50N/5CM | White, brown, black |
| 0.90 | 2600 | 3267N±50N/5CM | White, brown, black |
| 1.0 | 2600 | 3822N±50N/5CM | White, brown, black |
These figures describe this range. Confirm the required thickness, finished width, endless circumference, color and construction as a complete specification. The table does not state a test method or allowable working load; do not use its tensile figures alone to determine operating belt tension.
Application and Belt Selection
Screen-printing dryers, tunnel dryers and microwave-processing conveyors can have different belt, tracking and operating requirements. Select a replacement against the machine specification rather than by color or thickness alone. Where edge guides, reinforcement or a particular joint are required, include those details in your enquiry so the construction can be confirmed.
For high-temperature service, provide the normal operating temperature, peak temperature, exposure duration, conveyed material and cleaning conditions. Suitability for your process should be confirmed for the finished belt. This page does not assign a continuous operating-temperature rating or imply that every option is suitable for every machine.
Frequently Asked Questions
Which thicknesses are available?
The eight thicknesses are 0.25, 0.30, 0.35, 0.50, 0.65, 0.75, 0.90 and 1.0 mm. Refer to the table for the maximum width and tensile notation associated with each thickness.
Is 2600 mm the width of every belt?
No. It is the maximum width for thicknesses from 0.30 to 1.0 mm. The 0.25 mm option has a maximum width of 2400 mm. State your required finished width and endless circumference when requesting a quotation.
Does endless mean seamless?
Endless describes the closed-loop belt configuration. Seamless construction is not specified for these options. Confirm any joint or seam requirements before ordering.
What should I include in a wholesale enquiry?
Provide thickness, finished width, endless circumference, color and quantity, together with the equipment application and operating conditions. Include any required edge-guiding, joint or reinforcement details. Availability and suitability of the requested combination need confirmation.
Request a PTFE Conveyor Belt Quotation
For wholesale orders from our China factory, contact IKSONIC with your belt dimensions and application details. Specify the complete belt requirement so that dimensions, construction and process suitability can be reviewed together.
Worldwide Shipping
We ship worldwide. International express delivery usually takes 3–7 days after dispatch, excluding production and order preparation time. Actual transit time depends on the destination and customs clearance. For oversized or heavy shipments, the shipping method and transit estimate are confirmed separately.
