Clear Food-Grade Silicone Hose: 55 Listed Sizes

Description

Clear Food-Grade Silicone Hose

IKSONIC supplies clear silicone hose described as food-grade in the product source. This selection includes 55 listed size combinations, with inside diameter, outside diameter, wall thickness and listed length shown separately. Choose the complete specification rather than ordering by inside diameter alone.

As a China-based supplier, IKSONIC supports wholesale enquiries from equipment manufacturers, factory purchasing teams and maintenance buyers. The source identifies water tubing and drinking-water dispenser applications; suitability for your particular equipment and contact conditions should be confirmed before ordering.

Specifications and Sizes

Tube dimensions are in millimeters. The source lists lengths of 1, 2 or 5 m depending on the size. The length shown on each row preserves that correspondence and is not a minimum-order or packaging promise. Confirm the supplied length and quantity with your enquiry.

Inside diameter (mm)	Outside diameter (mm)	Wall thickness (mm)	Listed length (m)
2	3	0.5	5
2	4	1	5
2	5	1.5	5
2	6	2	5
3	4	0.5	5
3	5	1	5
3	6	1.5	5
3	8	2.5	5
4	5	0.5	5
4	6	1	5
4	7	1.5	5
4	8	2	5
4	9	2.5	2
4	10	3	2
5	6	0.5	5
5	7	1	5
5	8	1.5	5
5	9	2	2
5	10	2.5	2
6	7	0.5	5
6	8	1	5
6	9	1.5	2
6	10	2	2
6	12	3	2
7	9	1	5
7	10	1.5	2
7	11	2	2
7	12	2.5	2
8	10	1	5
8	11	1.5	2
8	12	2	2
8	14	3	1
9	12	1.5	2
9	13	2	2
10	12	1	5
10	13	1.5	2
10	14	2	2
10	15	2.5	1
10	16	3	1
12	14	1	2
12	15	1.5	2
12	16	2	1
12	18	3	1
13	18	2.5	1
14	18	2	1
14	20	3	1
15	20	2.5	1
16	20	2	1
16	21	2.5	1
16	22	3	1
19	25	3	1
20	25	2.5	1
20	26	3	1
25	31	3	1
32	38	3	1

Material and Operating Requirements

The product is described as clear, food-grade silicone rubber hose. The source main image lists a temperature range of −50°C to 260°C, without test conditions or a continuous-service limit. Confirm suitability for the actual operating temperature, exposure duration and contact medium before ordering.

No specific FDA, LFGB or other certification is assigned by this page. If a compliance report is needed, state the intended use and documentation requirement so the available supporting information can be reviewed. The food-grade description does not establish suitability for every food, cleaning process or operating condition.

Selecting the Correct Hose

Match inside diameter to the required flow path and outside diameter to the mating fitting or clamp arrangement. The table also states wall thickness, which differs between sizes sharing the same inside diameter. Do not assume that hoses with the same bore are interchangeable.

For replacement work, use the machine specification or the markings and measurements of the existing hose. Include any tolerance, hardness, pressure or vacuum requirement in your enquiry. Those values are not established by this listing, and photographs cannot be used as dimensional drawings.

Frequently Asked Questions

How many sizes are listed?

There are 55 diameter and wall-thickness combinations. Inside diameters run from the listed 2 mm options through the 32 mm option. Only the pairings in the table are listed; this does not imply that every possible combination is available.

Is every size supplied in the same length?

No. The listed length depends on the size and is shown in the last column. Confirm the total length, individual lengths and packaging needed in your enquiry rather than applying one row’s length to all models.

What should I provide for a food-contact enquiry?

State the intended contact medium, temperature, cleaning method and required compliance documentation. This helps distinguish a general food-grade product description from the exact requirements of your application.

Can the hose be cut to length?

You may enquire about required cut lengths. Provide the length tolerance and quantity so processing requirements can be reviewed; a request does not confirm that a particular cutting service or tolerance is available.

Request a Wholesale Quotation

Contact IKSONIC with the inside diameter, outside diameter, wall thickness and quantity. Include the required length and operating conditions so the complete specification can be checked before quoting.
