Industrial Silicone Tubing with Cut-Length and Coil Options
IKSONIC manufactures industrial tubing from virgin silicone material, with 54 ID/OD pairs and cut-length or whole-coil options. Confirm dimensions, length, tolerances and service conditions for your order.
- Description
- Contact Us
Description
Industrial Silicone Tubing from China
IKSONIC manufactures industrial silicone tubing in a range of inside and outside diameters for wholesale inquiries. We produce this tubing in China from virgin silicone material. Choose the required bore, outside diameter and length from the table below, then confirm suitability for the service conditions.
Material and Manufacturing Information
- Material: virgin silicone.
- Manufacturing origin: China-made silicone tubing, not an imported finished tube.
- Manufacturing processes: extrusion molding and compression molding. Confirm the manufacturing method for the selected item or custom configuration.
- General features: aging resistance, flexibility, heat resistance, tear resistance and translucent appearance. Confirm the formulation and performance requirements for your application.
- Temperature range: −60 to 200°C. Confirm the selected formulation, exposure duration, fluid and operating conditions before using this as an application limit.
Confirm the allowable pressure for the selected tubing. Do not treat wall appearance or the temperature range as proof of an allowable working pressure. Ask for product-specific technical evidence where pressure, temperature or chemical exposure matters.
Specifications and Length Options
Each row pairs cut-length and whole-coil options for the same inside and outside diameter. ID and OD are in millimetres; lengths are in metres. Confirm quantity, packaging and any required uninterrupted length when requesting a quotation.
| Inside diameter / ID (mm) | Outside diameter / OD (mm) | Cut-length option (m) | Whole-coil length option (m) |
|---|---|---|---|
| 2 | 4 | 5 | 833 |
| 2 | 5 | 5 | 476 |
| 2 | 6 | 5 | 313 |
| 3 | 5 | 5 | 625 |
| 3 | 6 | 5 | 370 |
| 3 | 8 | 1 | 182 |
| 4 | 6 | 5 | 500 |
| 4 | 8 | 1 | 208 |
| 4 | 10 | 1 | 119 |
| 5 | 6 | 5 | 909 |
| 5 | 7 | 5 | 417 |
| 5 | 8 | 1 | 256 |
| 5 | 10 | 1 | 133 |
| 6 | 7 | 5 | 769 |
| 6 | 8 | 5 | 357 |
| 6 | 9 | 1 | 222 |
| 6 | 10 | 1 | 156 |
| 6 | 12 | 1 | 93 |
| 7 | 9 | 1 | 313 |
| 7 | 10 | 1 | 196 |
| 7 | 11 | 1 | 139 |
| 7 | 12 | 1 | 105 |
| 7 | 13 | 1 | 83 |
| 8 | 10 | 5 | 278 |
| 8 | 11 | 1 | 175 |
| 8 | 12 | 1 | 125 |
| 8 | 14 | 1 | 76 |
| 9 | 12 | 1 | 159 |
| 9 | 13 | 1 | 114 |
| 9 | 14 | 1 | 87 |
| 10 | 12 | 1 | 227 |
| 10 | 13 | 1 | 145 |
| 10 | 14 | 1 | 104 |
| 10 | 16 | 1 | 64 |
| 10 | 18 | 1 | 45 |
| 12 | 14 | 1 | 192 |
| 12 | 16 | 1 | 89 |
| 12 | 18 | 1 | 56 |
| 13 | 18 | 1 | 65 |
| 14 | 16 | 1 | 167 |
| 14 | 18 | 1 | 78 |
| 15 | 20 | 1 | 57 |
| 16 | 20 | 1 | 69 |
| 16 | 21 | 1 | 54 |
| 17 | 22 | 1 | 51 |
| 18 | 22 | 1 | 63 |
| 19 | 25 | 1 | 38 |
| 20 | 26 | 1 | 36 |
| 22 | 26 | 1 | 52 |
| 25 | 31 | 1 | 30 |
| 25 | 35 | 1 | 17 |
| 30 | 36 | 1 | 25 |
| 32 | 38 | 1 | 24 |
| 38 | 44 | 1 | 20 |
Choose from the 54 dimensional pairs above. Confirm wall-thickness, tolerance and pressure requirements for your application. Specify the required tolerances separately if the tubing must fit a particular connector, sleeve or equipment interface.
Custom Tubing Inquiries
We offer custom thickness, slitting and cutting. Please specify the required inside diameter, outside diameter, shape, color and other manufacturing requirements for your order.
- State the inside diameter, outside diameter, quantity and required continuous or cut length.
- Describe the fluid or contact medium, temperature, pressure and installation arrangement.
- Provide any required color, slit, cut-end finish or special profile details.
- Identify material documentation and inspection requirements before ordering.
Frequently Asked Questions
Does the reference temperature range apply to every operating condition?
No. The −60 to 200°C range must be checked against your exposure and duty conditions. Confirm the selected tubing’s suitability for your fluid, pressure, temperature and service duration.
Are the cut lengths the minimum order quantities?
No minimum order quantity is established here. The table records the length options only. Include your total quantity and packaging requirements in the inquiry.
Can I order a different diameter or a slit tube?
We offer customization, including thickness, slitting and cutting. Please provide the complete manufacturing specification and quantity for a quotation.
Is this tubing certified for food or medical use?
Food-contact or medical requirements need application-specific review. Request application-specific material and compliance documentation rather than assuming a grade from the appearance.
Request a Quotation
For wholesale industrial silicone tubing, contact IKSONIC with your tubing requirements. Include the selected ID and OD, length, quantity and service conditions.
Worldwide Delivery
Manufactured in China and shipped worldwide. For orders suitable for international express, delivery typically takes 3–7 days after dispatch, excluding production and order preparation. Transit times vary by destination and customs clearance. Confirm the shipping method and estimated transit time for your order.
